SPECIFICATIONS

Brand Name: BETAFPV

Certification: CE,FCC

Drones Accessories Type: Data Transmission System

Fps: N/A

High-concerned chemical: None

Max. Transmission Distance: N/A

Origin: Mainland China

Package: Yes

Product Dimensions: 265mm x 170mm x 31mm

Resolution: 1024*600

Transmitter Power (EIRP): N/A

Weight: 700g

Note:  There is no LOGO on the monitor Captain X 3.3G & 1.2G, because of sensitive issues

Features:

Specially designed for aerial photography system, CAPTAIN all-in-one monitor

has the following features:

High brightness: 1000 Lux.

DVR : integrated DVR black box can run in the background for recording.
No delay/anti blue screen/anti black screen: the built-in DVR system won’t
cause any delay in receiving signal; blue screen or black screen will definitely not
occur.

Auto/manual channel scan: no need for DIP switch.

HDMI input.





Display resolution 1024×600

Backlight LED

Brightness 1000 Lux

Aspect ratio 16：9

Response time 10ms

Color system PAL/NTSC

Working voltage DC：3S-6S battery

Current 1A @3S；550MA @6S;

Input Signal Video（PAL/NTSC），HDMI

Output Signal Video
5V(input power >12V) 1A

DVR Resolution D1/VGA/QVGA

TF card supported Max 64G

Packing size 300mm×200mm×60mm

Monitor size 265mm×170mm×31mm

Gross weight 1.13kg

Sensitivity -99dB

Matching antenna

interface interface SMA
